Freight Equipment
Freight Equipment of the Danville & Western| Type | Car Numbers | Dimensions | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inside | Outside | Doors | |||||||||||||||
| D&W | Re-lettered SOUTHERN | Height | Side | End | Capacity | # of Cars | Note | ||||||||||
| L. | W. | H. | L. | W. at Eaves | Eaves | Overall | W. | H. | W. | H. | Cu. Ft. | Tons | |||||
| F | 500-506 | 400002-400007 | 33' | 9'3" | 33' | 9'3" | 25 | 5 | 1 | ||||||||
| F | 507,508 | 400000,400001 | 36' | 9'3" | 36' | 9'3" | 25 | 2 | 1 | ||||||||
| F | 550 | 400020 | 38' | 9'5" | 38' | 9'5" | 30 | 1 | 2,13 | ||||||||
| B | 717-766 | 400100-400146 | 36'10" | 8'3" | 7'2" | 37'2" | 9'3 3/4" | 11'8 1/2" | 12'7" | 6' | 6'9" | 30 | 47 | 3,12 | |||
| G | 801 | 400800 | 33' | 9'3" | 33' | 9'3" | 20 | 1 | 4 | ||||||||
| G | 900-911 | 400900-400911 | 28' | 8' | 28' | 8' | 20 | 12 | 5 | ||||||||
| S | 1001,1002 | 400700,400701 | 36'10" | 8'6" | 7'6" | 37'2" | 9'3" | 11'10" | 30 | 2 | 6,7,11 | ||||||
| B | 1100-1199 | 400147-400246 | 36'10" | 8'6" | 8' | 37'2" | 9'6" | 12'7" | 14' | 6' | 6'9" | 30 | 100 | 8,9 | |||
| V | 2000-2009 | 400500-400508 | 36'10" | 8'3" | 7'2" | 37'2" | 9'3 3/4" | 11'8 1/2" | 12'7" | 6' | 6'9" | 2468 | 30 | 9 | 9,10 | ||
| V | 2010-2049 | 400509-400547 | 36'10" | 8'6" | 8' | 37'2" | 9'6 1/2" | 12'6" | 14' | 6' | 7'6 3/4" | 2' | 3' | 2476 | 30 | 39 | 9,11 |
All cars listed had wooden bodies and frames except as noted below.
Notes:
- ICC Valuation shows cars 501-508 as 36', 20 ton capacity
- ICC Valuation indicates the length as 36'10"
- ICC Valuation indicates 48 cars in this series
- This car is classified as a 25'8" gondola in the ICC Valuation, a coal car in the OER
- These cars are classified as 25'8" ballast cars in the ICC Valuation, gondolas in the OER
- ICC valuation indicates the length as 36'
- OER indicated inside length as 35'10, value shown is speculation
- These cars are not in the ICC Valuation. They presumably had steel underframes
- OER indicates inside length as 36'
- No outside length known, value shown is speculation
- OER indicated outside length as 37', value shown is speculation
- Built by Lenoir Car Works in 1908
- Built by Lenoir Car Works in 1913, steel underframes
